1 Bay Pallet Racking System – 6 Pallet Storage Capacity (3660mm High)
Upgrade your warehouse, workshop, or retail storage with our heavy-duty 1 Bay Pallet Racking System, designed to safely store up to 6 pallets. Built from premium steel and manufactured in compliance with AS 4084-2023 Australian Standards, this system combines strength, safety, and cost-efficiency.
✅ Key Benefits
-
Easy to install (DIY) – with optional professional installation service.
-
Adjustable beam levels – configure heights to suit your storage requirements.
-
Cost-effective solution – maximise warehouse space and improve efficiency.
-
Heavy-duty build – engineered for strength, safety, and long-term durability.
Specifications
-
System Size (1 Bay, 3 Levels): 2790mm (L) x 3660mm (H) x 838mm (D)
-
Compatible: DEXION style racking – integrates with existing systems
-
Certification: ISO 9001 (SGS)
-
Compliance: Manufactured to AS 4084-2023 standards
-
Construction: High-grade steel, powder-coated finish
-
Design: 3 storage levels
Frame Details
-
Dimensions: 3660mm (H) x 90mm (W) x 838mm (D)
-
Load Capacity: Up to 8 tonnes per frame
-
Finish: Blue powder-coated
-
Includes:
-
2x Upright posts
-
2x Base plates
-
Support bars, bolts & nuts
-
Fully assembled frames for convenience
-
Beam Details
-
Dimensions: 2690mm (L) x 100mm (H) x 45mm (D)
-
Clear Entry: 2590mm usable length
-
Capacity: Certified up to 2 tonnes per pair
-
Finish: Orange powder-coated for visibility & safety
-
Locking System: Speedlock safety pins included for added protection
Key Features
-
High-visibility beams – safety-orange finish.
-
Quick installation – minimal tools required.
-
Easy height adjustment – flexible for changing warehouse needs.
-
Secure keyhole connection – prevents accidental dislodgement while maintaining strength and rigidity.
Package Includes
-
2x Frames (fully assembled)
-
4x Beams
-
8x Speedlock safety pins
-
8x Dynabolts for secure floor fixing
(3660_1bay)
SKU | 3660_1bay |
Brand | mrpalletracking |
Shipping Weight | 250.0000kg |
